Mitsubishi Lancer WRC2 technical specs.

For any techies...! A complete technical specification for the Mitsubishi Lancer Evolution WRC2, which will make its debut on next week's Neste Rally of Finland.

DIMENSIONS

OVERALL LENGTH 4360mm
OVERALL WIDTH 1770mm
WHEEL BASE 2600mm
FRONT TRACK 1550mm
REAR TRACK 1550mm

ENGINE

MODEL 4G63
TYPE 4 Cylinders, 16-Valve DOHC- Intercooled Single Scroll
Turbocharger with Post Combustion Control System
FUEL SYSTEM ECI Multi-injection
BORE x STROKE 85.5mm x 86.9mm
DISPLACEMENT 1996cc
MAXIMUM OUTPUT 220Kw(300ps)/5500rpm
MAXIMUM TORQUE 540Nm(55kg-m)/3500rpm

CLUTCH Carbon Triple Plates
TRANSMISSION 6 Speed INVECS type Shift
4WD SYSTEM Active Control Locking System
FRONT DIFF Active Control Locking System
REAR DIFF Active Control Locking System

SUSPENSION

Front - Independent- MacPherson strut with coil spring
Rear - Independent- MacPherson strut with coil spring

DAMPER Ohlins with adjustable system
STEERING Power assisted rack & pinion

BRAKES

Front - Ventilated discs with 6-pot calipers
Rear - Ventilated discs with 4-pot calipers

TYRES Michelin
WHEEL Enkei
