Toyota TF105 - technical specifications.

Complete technical lowdown on the new Toyota TF105, launched today [Saturday] in Barcelona, Spain.

Chassis - Toyota TF105:

Monocoque construction: Moulded carbon fibre and honeycomb construction.

Fuel tank: ATL safety cell.

Front suspension: Carbon fibre double wishbone arrangement, with carbon fibre trackrod and pushrod Pushrod activates rocker, torsion bar, damper and anti roll bar assy.

Rear suspension: Carbon fibre double wishbone arrangement, with carbon fibre toelink and pushrod Pushrod activates rocker, torsion bar, damper and anti roll bar assy.

Dampers: Sachs/Toyota.

Wheels: BBS forged magnesium.

Tyres: Michelin.

Brakes callipers: Brembo.

Brakes master cylinders: Brembo.

Braking material: Hitco (carbon/carbon).

Steering: Toyota power-assisted steering.

Steering wheel display: Toyota carbon fibre wheel with Toyota/Magneti Marelli instrument.

Driver seat: Carbon fibre construction, moulded to driver's shape.

Driver restraints: Sparco.

Driver HANS device: Toyota design.

Electronic systems: Toyota/Magneti Marelli.

Transmission: 7-speed unit plus reverse. Toyota-designed maincase with Toyota/Xtrac internals. Gear selection is sequential, via driver controlled electro-hydraulic actuation.

Dimensions:

Wheelbase: 3,090mm

Overall length: 4,530mm

Overall height: 950mm

Overall width: 1,800mm

Overall weight: 600kg including driver and camera

Engine - RVX-05:

Designation: RVX-05

Number of cylinders: 10

Capacity: 2998cc

Horsepower: More than 900bhp

Revolutions: Approximately 19,000rpm

Valve actuation: Pneumatic

Throttle actuation: Hydraulic

Spark Plugs: DENSO

Fuel: Esso

Lubricants: Esso
